Humminbird

Humminbird APEX 19 VX MSI+ Chartplotter/Fishfinder with Transom Mount Transducer

SKU 411240-1vx-015
$4,999.99
$4,699.99
$4,999.99
$4,699.99

Product Details
FEATURES
  • Full-HD Display with Cross Touch® interface

APEX delivers eye-popping detail with a 1920H x 1080V display. See the incredible detail of sonar and chart images that will ensure you never miss a thing. Control it all using the touchscreen or the keypad—it's up to you.

  • Includes LakeMaster® and CoastMaster® VX Maps

Navigate over 13,000 lakes, waterways, and coastal waters in the United States and Canada safely and with confidence. Tools like 1-foot contours, depth and shallow water highlights help you traverse waters with certainty.

  • Industry-leading Humminbird sonar

Equipped with MEGA Side Imaging+, MEGA Down Imaging+ and Dual Spectrum CHIRP sonar to keep you on the fish. MEGA Imaging+ provides views up to 250' under and out to either side of your boat and Dual Spectrum CHIRP shows exceptional 2D sonar with superior target separation and fish clarity.

  • Dual Channel CHIRP Sonar

Dual sonar ports offer connection with any Humminbird sonar options, as well as a dedicated port for 2D CHIRP transducers up to 2kW. Integrated transducer ID provides fast and simple installation of Airmar® transducers.

  • Customized Experience

Utilize an intuitive user interface and sidebar menu which provide customizable settings and view combinations to make your fishing experience all your own.

  • Internal GPS and Humminbird Basemap

Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.

  • Premium Chart Compatible

Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird's LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.

  • AutoChart Live

Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually-endless AutoChart Live mapping capacity.

  • One-Boat Network® Compatible

Seamlessly integrate and communicate with Minn Kota motors and Cannon Optimum downriggers to unlock more features and capabilities for anglers everywhere. Make the most of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network®.

  • Dual Ethernet Ports

Build a powerful, professional-grade fishing system with dual Ethernet ports on APEX chartplotters. Easily network products without the need for an external network hub, allowing the connection of multiple control heads and Ethernet accessories like Minn Kota Advanced GPS Motors and Humminbird CHIRP Radar.

  • HDMI Compatible

See it all with independent HDMI In and HDMI Out ports on APEX. Connect and view accessory camera and video sources, as well as output to accessory displays for more viewing and rigging options.

  • Bluetooth

Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird One-Boat App.

  • NMEA 2000 Networking Built-in

Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.

  • Includes control head, Lakemaster and Coastmaster U.S./Canada VX Map Card,screen cover, transom mount transducer, mounting hardware, power cable, and gimbal mounting bracket. Product comes with 2-Year Limited Warranty.
  • APEX's low-profile design provides a sleek look at the helm when installed with the included front-mount in-dash kit.
  • In-Dash Installation Note: If indash mounted, an external GPS antenna is required to ensure accurate positioning and navigation.
  • Compatible with MEGA Live 2 Sonar: Watch fish move, react, and strike your lure with the next-gen clarity of MEGA Live 2 in Forward or Down Mode, now with real-time zoom (Sold Separately).

    WHAT'S IN THE BOX
  • APEX Control Head
  • 10 ft Power Cable(1)
  • LakeMaster/CoastMaster Map Card
  • APEX Mounting Bracket & Mounting Hardware
  • Premium Silicone Unit Cover
  • XM 14 HW MSI T - Transom-Mount Transducer

Warranty

Openairlifestyles.com honors all manfacturer's warranties. This GPS/Fishfinder comes with a 1 or 2 year limited warranty from Humminbird as specified below. __________________________________________

The Humminbird warranty offered is product dependent. The warranty begins at the date of purchase. When requiring any service/repairs for your Humminbird product, you will need your original receipt of purchase for warranty coverage. If you do not have your receipt of purchase, we will reference your product's serial number and base your warranty coverage off the date of manufacture. We recommend that you write the serial number down somewhere outside of your boat to have it available for future reference.

Humminbird 2-Year Limited Warranty

This warranty covers the following products:

  • All XPLORE modelsOptional: Additional third year of warranty is available with product registration.*
  • All APEX models
  • All SOLIX models
  • HELIX 8 / 9 / 10 / 12 / 15 models
  • ICE HELIX 9 models (with MEGA Live or MEGA 360 Imaging)
  • ICE Flasher models (ICE-55, ICE-45, and ICE-35)
  • MEGA Live 1 Imaging transducers
  • MEGA Live 2 Imaging transducers
  • MEGA 360 Imaging transducers

Download Humminbird 2-Year Limited Warranty Terms (PDF)



Humminbird 1-Year Limited Warranty

This warranty covers the following products:

  • HELIX 5 / 7 models
  • ICE HELIX 5 / 7 models
  • All accessories
  • All cartography products

Download Humminbird 1-Year Limited Warranty Terms (PDF)



Humminbird Cartography 1-Year Limited Warranty

This warranty covers the following products:

  • All cartography products including LakeMaster and CoastMaster charts

Download Humminbird Cartography 1-Year Limited Warranty Terms (PDF)

Humminbird Owners/Installations Manuals

Popular Models

Apex/Explore/Solix Series Operations Manual

Apex Series Control Head Installation Guide

Apex/Solix Quick Start Guide

APEX Series In Dash Mounting Installation Guide

Transom Mount Transducer Installation Guide

Thru Hull Stainless Steel Transducer Mounting Template

Thru Hull Stainless Steel Transducer Installation Guide

XPLORE Series Control Head Installation Guide

XPLORE Quick Start Guide

XPLORE Series In Dash Mounting Installation Guide

Estimated shipping time

You can typically expect your Humminbird product to be delivered by Fedex, UPS, or USPS and arrive within 5-7 business days, depending on your location and product availability. See our Shipping Policy for more info.

What is your Return Policy?

At openairlifestyles.com, we want your shopping experience to be simple and worry free. If something isn’t quite right, our return and refund process is designed to be clear, fair, and hassle free.

Occasionally mishaps may occur. We believe all issues can be resolved fairly, if given a chance. If you have any concerns that need corrected, please contact us to discuss and we will work together to resolve them.

Returns:

  • You may return most items within 30 days of the delivery date.
  • Unfortunately, we are unable to accept returns submitted after 30 days.
  • If the item is defective or incorrect, we’ll get the item back and either replace it or issue a refund.
  • Changed your mind, no problem, any returns for unused items in original packaging are accepted within 30 days. You’ll be responsible for the shipping both ways. Once we receive and inspect the returned item and everything is in the same condition as when shipped, we’ll issue a refund for the product (minus any shipping fees).
  • If your item arrives broken, malfunctioning, or with missing parts, please contact us within 30 days of delivery. We’ll arrange a return, resend missing parts, or make it right at no cost to you. Please contact us ASAP and provide the order information and any pictures so we can understand what is going on. Once the item is shipped back and inspected, we’ll either send a replacement or issue a refund.
  • Once your return is received and approved, we’ll notify you via email. Refunds are typically issued to your original payment method within 3-4 business days.
    Please note: Your bank or card provider may take additional time to post the refund. If you haven’t received your refund after 7 business days, feel free to contact us at support@openairlifestyles.com.

Restocking Fees:

  • Some returns may be subject to a restocking fee, depending on the product and reason for return. We’ll always inform you in advance if this applies.

Questions:

We're here to help! For any return or refund inquiries, reach out to our Customer Support team at support@openairlifestyles.com.

Or give us a call at 1.888.625.6055
Authorized Dealer
USA Company
Quick Fulfillment

Humminbird APEX 19 VX MSI+ Chartplotter/Fishfinder

with a Transducer



The APEX 19 MSI+ Chartplotter provides the clearest sonar imaging on the sharpest multi-function display that anglers have ever seen. See it all with a 18.5" Full-HD touchscreen that provides a customized display of information from advanced network options like NMEA 2000®, HDMI In/Out, WiFi and Bluetooth®. Find your fishing spots faster with included LakeMaster® and CoastMaster® VX Maps. Navigate over 13,000 lakes, waterways, and coastal waters in the United States and Canada with confidence. Tools like 1-foot contours and depth and shallow water highlights help you traverse waters with certainty. Industry-leading MEGA Imaging+ and Dual Spectrum CHIRP sonar come standard, with even more performance from a dedicated sonar channel for accessory 2D CHIRP transducers up to 2kW. Add the power of the One-Boat Network™ to integrate the accuracy of Humminbird GPS charts, unrivaled boat control from Minn Kota®, and reach new depths with wireless Cannon® Optimum™ downrigger control. The APEX Series is a new kind of MFD that will take you fishing to a new level.


SPECS

Model APEX 19 MEGA SI+ CHARTPLOTTER
Product Code 411240-1VX
Series APEX
UPC 0082324061653
Display Size - Diagonal 18.5 in
Length 11.66 in | 29.62 cm
Height 20.27 in | 51.49 cm
Width 5.33 in | 13.54 cm
Weight 13 lb 8 oz | 6.1235 kg
Display Pixel Matrix 1920H x 1080V
Transducer Included XM 14 HW MSI T
Compatible With Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, Minn Kota Talon/Raptor, Minn Kota i-Pilot Link, Minn Kota Built-In MEGA SI, HDMI In/Out, MEGA Live, AIS, NMEA 2000, MEGA 360, Radar, AutoPilot, One-Boat Network, MEGA Live 2
Features Touch Screen, MEGA Live Imaging, Networking, Down Imaging, Built In GPS, Side Imaging, Dual Spectrum CHIRP, Built In Mapping, MEGA Imaging+, Wi-Fi
Memory Card Slot Dual Micro SD
Sonar-Standard Dual Spectrum CHIRP, MEGA Side Imaging+, MEGA Down Imaging+
Sonar-Coverage 20°, 42°, 60° & (2) 86° @ -10dB
Sonar-Optional 50/83/200 kHz, Airmar High, High Wide, Medium, Medium Wide, and Low
CHIRP - Frequencies Supported Narrow Mode (180-240 kHz), Optional Deepwater (28-250 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz)
Sonar-Frequencies Supported 50/83/200/455/800 kHz, HW DSC CHIRP, and MEGA
Depth-Sonar 3,500 ft (optional Airmar CHIRP), 1,200 ft (standard transducer)
CHIRP - Imaging Frequencies Supported MEGA DI+ (1100-1200 kHz), 800 kHz SI+ (780-840 kHz), 455 kHz SI+ (405-505 kHz), 800 kHz DI+ (800-860 kHz), MEGA SI+ (1050-1175 kHz), 455 kHz DI+ (420-520 kHz)
Depth-Down Imaging 250 ft (MEGA), 400 ft (455 kHz), 125 ft (800 kHz)
Range-Side Imaging (Side-To-Side) 800 ft (455 kHz), 500 ft (MEGA), 250 ft (800 kHz)
Interface Touch Screen
Power Draw 4.4 Amps
Power Input 10.8-20 VDC
Power Output Peak-to-Peak 8000 Watts
Power Output RMS 1000 Watts
Screen Snap Shot Included
Sonar Recording Included
Mount-Standard Gimbal
Mount-Standard Size 20.27 in W x 12.58 in H x 4.95 in D
Mount-Optional In-Dash Mounting Kit
Mount-Optional Size 20.27 in W x 11.66 in H x 0.51 in D
Transducer Mount Location Transom
GPS Chartplotting Included
GPS Receiver Internal
GPS Trackplotting Included
Waypoints, Routes, Tracks/Points 10,000, 50, 50/20,000
360 Imaging Compatibility Yes
MEGA Live Compatibility Yes
Humminbird Basemap Included
LakeMaster Compatibility Yes
CoastMaster Compatibility Yes
Navionics Gold/HotMaps Compatibility Yes
Navionics Platinum+ Compatibility Yes
Platinum Compatibility Yes
Minn Kota Advanced GPS Navigation Compatibility Yes
Minn Kota i-Pilot Link Compatibility Yes
Minn Kota Talon Shallow Water Anchor Compatibility Yes
Radar Compatibility Yes
5-Port Ethernet Switch Compatibility Yes
AIS Compatibility Optional
Autopilot Compatibility Yes
Heading Sensor GPS Compatibility Yes
Heading Sensor GPS (NMEA 2000) Compatibility Yes
NMEA2000 Included
Target Separation 2.5 in
Upgradable Software Yes
View Preset Keys Yes
X-Press Menu System No
Custom Digital Readout Yes
Custom View Selections Yes
Display Colors Grayscale 16-Bit
Display Type Color TFT
Speed Included
Temperature Built In
Temperature Alarm Yes
Temperature Graph Yes
HDMI Compatible Yes
Warranty Two-Year Warranty

See Clearly in Full HD..... The best sonar and mapping on the sharpest display anglers have ever seen in 1920x1080 resolution to quickly identify your targets.
Includes LakeMaster & CoastMaster VX Maps..... Navigate over 13,000 lakes, waterways, and coastal waters in the United States and Canada safely and with confidence.
Sun-Viewable Display..... Goodbye glare. Our glass-bonded display delivers exceptional readability, even in full sun.
